Our clients can avail Cannonball3 continuous Sample Draw Multi-Gas Detectors supplied by Gas Alarm Marketing, for detection and monitoring multi gases in confined area, process plants etc.
Gas available : LEL, combustibles, O2, CO, H2S, SO2, NH3, CL2, NO2, flammables, LPG, propane, hydrocarbons, ammonia, PH3, CO2
Cannonball 3 includes a sealed case coupled with an oversized, scratch-resistant, self-healing display. The Cannonball 3 can be configured to detect oxygen, combustible gases and vapors and a wide variety of toxic hazards. The optional high sensitivity HC-PPM LEL provides broad range monitoring at PPM levels for nearly all toxic and combustible gases and vapors to address a wide range of health and safety concerns. The gas sample is drawn into the Cannonball 3's internal sensor chamber by a field-replaceable internal pump module. As an option, the Cannonball 3 may be equipped with a Dilution Pump module, which allows for the proper monitoring of combustible gases and vapors in oxygen-deficient or inert (oxygen-free) atmospheres without a dilution orifice or labor-intensive manual calculations. More features than any other Sperian gas detector and rugged enough for the harshest environmen
Features:
Rugged RFI-protected case designed for the most demanding environments.
IPX5 rated protection against dust and water.
One button operation.
Oversized (5" diagonal) backlit graphic display with automatic backlight.
Four sensors. O2, LEL and up to three toxic channels using Biosystems’ Duo-Tox two channel CO/H2S sensor (see matrix for available sensors).
User replaceable sensors.
One button auto calibration.
Calibration due reminder.
Sensor span reserve indicators during calibration for predictive maintenance.
HC-PPM sensor.
IQ compatible.
Pumps:
Field replaceable pump module.
Available with dual pumps for accurate dilution monitoring in inert environments without the use of a dilution orifice.
Dilution calibration regardless of tube length.
Automatic low flow alarm.
Automatic leak test before every use.
Recording:
Black-Box recorder with over 100 hours of storage.
Available with optional datalogging for convenient and easy downloading to a computer.
Hazards:
Confined Space
Extreme Environment
Gas, Vapors, Smoke
Recommended Industries/Use
Chemical
Oil and Gas
Sewage
Waste Treatment Plant
Water Treatment Plant
Thermal Power Plant
Process Industries
Food, Beverage Industries
Automobile
Bottling Plants
Oil & Gas
Onshore, Offshore Platform
Hazardous Area
Heavy Water Plant
Nuclear Plant
Dilution Pump
When monitoring for combustible gas in areas where the oxygen concentration is less than 10 percent, the Cannonball3 can be equipped with a special internal dilution pump module. The dilution module contains two pumps so the instrument can independently measure the sample and dilution flows and then calculate and display corrected sample readings.
Instrument Type
Confined space multi-gas detector, replaceable battery pack and sensors
Dimensions
12" x 6.25" x 6" in (30 x 16 x 15 cm)
Weight
7 lbs./3.2kg (including battery pack)
Smart Sensors and Calibration
Four sensors. O2, LEL and up to three toxic channels using Duo-Tox two channel CO/H2S sensor. One button auto calibration. Calibration due reminder. Sensor span reserve indicators during calibration for predictive maintenance.
Sensor Type
Electrochemical, Catalytic Bead
Alarms
Peak, Overrange, TWA, STEL and Ceiling
Audible Alarm
Loud two-toned audible alarm rated at 105dB
Visual Alarm
Three bright-red LED alarm-lights visible on all sides
Low Battery Alarm
Standard
Dilution Alarm
O2 Low and Ceiling Alarms
Display
Displays up to 5 gases on a large top-mounted graphics type LCD. Scratch-resistant, self healing urethane overlay keeps the display clear and easy to read even after years of use.
Display Backlight
Automatically activated in dark or dimly lit areas
Controls
One button operation including automatic calibration
Shoulder Strap
Standard
Black Box Data Recorder
Standard: Stores over 100 hours of readings and other data
Readouts
Varies by Operating Mode: Text only, Basic, Basic/Peak, Technician
Battery Packs
Rechargeable nickel metal hydride (NiMH) or disposable alkaline (5 "D"cell) battery packs. Operating life: NiMH: up to 16 hours, Alkaline: up to 24 hours. Snap-on fast charger included with rechargeable (NiMH) configuration. Recharges in 4 hours.
Housing
Gasketed, water-resistant case constructed of an ABS material with an internal metallic spray coating designed to minimize the effects of radio frequency interference.
Durability (IP Rating)
Meets IP65 for water and dust protection.
Standard Accessories Included
Built-in sample draw pump. Remote sampling probe with 10" of tubing and QD (quick disconnect) fittings. Shoulder strap. Rechargeable NiMH version includes charger. Operator's guide. Quick reference guide. Training video.
Datalogger
Provides convenient and easy downloading to a computer. Enables the Cannonball 3 to record and download measurements. This option is available as an upgrade after purchase. Download software must be purchased separately. Computer must support IrDA to download.
Pumps
Field replaceable pump module. Available with dual pumps for accurate dilution monitoring in inert environments without the use of a dilution orifice. Dilution calibration regardless of tube length. Automatic low flow alarm. Automatic leak test before every use.
Safety Certifications
• UL and C UL Class I, Division 1, Groups A, B, C & D, Temperature Code T3C CENELEC (DEMKO) Eex ia d IIC T3C
Readings Screen
Separate status line for dilution pump
